Programacion

using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Text;
using System.Windows.Forms;

namespace Dado_digital_UART_01
{
    public partial class Form1 : Form
    {
        public Form1()
        {
            InitializeComponent();
        }

byte[] buffer = { 1 };
        byte cnt = 1;

private void Form1_Load(object sender, EventArgs e)
        {
            serialPort1.Open();
            serialPort1.Write(buffer,0,1);
        }

private void button1_MouseDown(object sender, MouseEventArgs e)
        {
            timer1.Enabled = true;
        }

private void button1_MouseUp(object sender, MouseEventArgs e)
        {
            timer1.Enabled = false;
        }

private void timer1_Tick(object sender, EventArgs e)
        {
            if (cnt >= 6)
                cnt = 1;
            else
                cnt++;
            lblNumero.Text = cnt.ToString();
            buffer[0] = cnt;
            serialPort1.Write(buffer, 0, 1);
        }

private void Form1_FormClosing(object sender, FormClosingEventArgs e)
        {
            buffer[0] = 15;
            serialPort1.Write(buffer, 0, 1);
            serialPort1.Close();
        }
    }
}

Descargar archivo
