void main() {
  sound_init(&PORTC, 1);

while(1) {  //bucle infinito
    PWM1_Init(1633);  //Digito 0
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(941,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1209);  //Digito 1
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(697,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1336);  //Digito 2
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(697,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1477);  //Digito 3
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(697,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1209);  //Digito 4
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(770,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1336);  //Digito 5
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(770,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1477);  //Digito 6
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(770,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1209);  //Digito 7
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(852,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1336);  //Digito 8
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(852,200);
    PWM1_Stop();
    Delay_ms(800);

PWM1_Init(1477);  //Digito 9
    PWM1_Set_Duty(127);
    PWM1_Start();
    sound_play(852,200);
    PWM1_Stop();
    Delay_ms(800);
  }
}
